材料：不銹鋼
夾緊件：尼龍塑料（PA）
密封件：丁腈橡膠（NBR）
0-密封圈：丁腈橡膠（NBR）
防護等級：IP68-10巴壓力（旋緊部位）
環境溫度：-40℃至100℃，短時至120℃
產品特性：特殊夾緊爪與夾緊圈之設計，夾緊電纜范圍大，抗拉力特強，可防水、防塵抗鹽、耐弱酸、酒精、油、油脂及一般溶劑。
Material：Staninless steel
Claw：Nickel plastic(PA)
Sealing：NBR
0-Sealing ring：NRB
Protection level：IP68-10 bar pressure(fixed installation and with 0-sealing ring)
Ambient temperature： -40℃~100℃,temporary:to120℃
Character: Special design of clamping claw and clamping ring, wide clamping range, high stretching resistance, water proof, dust proof, salt resistant, resistant for weak acid, alcohol, oll, grease and general solvent.
型號
Model number
|
螺紋規格
Thread Dimension
|
接線范圍
Clamping range（mm）
|
螺紋外徑
AG（mm）
|
螺紋長度
GL
|
高度
H
|
扳手尺寸
Wrench Size（mm）
|
訂貨號
Article No.
|
包裝單位
Packet Units
|
|
TLYBFC-HSMS.NPT3/8.A
|
NPT 3/8"
|
4-8
|
17
|
15
|
21
|
17/19
|
19 00 017 3030 06
|
100
|
|
TLYBFC-HSMS.NPT3/8.B
|
NPT 3/8"
|
2-6
|
17
|
15
|
21
|
17/19
|
19 00 017 3031 06
|
100
|
|
TLYBFC-HSMS.NPT1/2.A
|
NPT 1/2"
|
6-12
|
21.2
|
13
|
24
|
22/24
|
19 00 017 3040 06
|
50
|
|
TLYBFC-HSMS.NPT1/2.B
|
NPT 1/2"
|
5-9
|
21.2
|
13
|
24
|
22/24
|
19 00 017 3041 06
|
50
|
|
TLYBFC-HSMS.NPT3/4.A
|
NPT 3/4"
|
13-18
|
26.5
|
13
|
25
|
30
|
19 00 017 3060 06
|
50
|
|
TLYBFC-HSMS.NPT3/4.B
|
NPT 3/4"
|
9-16
|
26.5
|
13
|
25
|
30
|
19 00 017 3061 06
|
50
|
|
TLYBFC-HSMS.NPT1.A
|
NPT 1"
|
18-25
|
33.2
|
19
|
29
|
41
|
19 00 017 3080 06
|
20
|
|
TLYBFC-HSMS.NPT1.B
|
NPT 1"
|
13-20
|
33.2
|
19
|
29
|
41
|
19 00 017 3081 06
|
20
|
型號
Model number
|
螺紋規格
Thread Dimension
|
接線范圍
Clamping range（mm）
|
螺紋外徑
AG（mm）
|
螺紋長度
GL
|
高度
H
|
扳手尺寸
Wrench Size（mm）
|
訂貨號
Article No.
|
包裝單位
Packet Units
|
|
TLYBFC-HSMS.G1/4
|
G1/4"
|
3-6.5
|
13.1
|
7
|
19
|
14
|
19 00 017 2020 06
|
100
|
|
TLYBFC-HSMS.G3/8
|
G3/8"
|
4-8
|
16.6
|
8
|
19
|
18
|
19 00 017 2030 06
|
100
|
|
TLYBFC-HSMS.G1/2
|
G1/2"
|
6-12
|
20.9
|
8
|
22
|
22
|
19 00 017 2040 06
|
50
|
|
TLYBFC-HSMS.G3/4
|
G3/4"
|
13-18
|
26.4
|
9
|
25
|
30
|
19 00 017 2060 06
|
50
|
|
TLYBFC-HSMS.G1
|
G1"
|
18-25
|
33.2
|
11
|
29
|
40
|
19 00 017 2080 06
|
20
|
|
TLYBFC-HSMS.G1-1/4
|
G1-1/4"
|
25-33
|
41.9
|
13
|
35
|
50
|
19 00 017 2100 06
|
10
|
|
TLYBFC-HSMS.G1-1/2
|
G1-1/2"
|
32-38
|
47.8
|
14
|
37
|
57
|
19 00 017 2120 06
|
10
|
|
TLYBFC-HSMS.G2
|
G2"
|
37-44
|
59.6
|
14
|
38
|
64
|
19 00 017 2140 06
|
5
|
|
TLYBFC-HSMS.G2-1/2
|
G2-1/2"
|
42-52
|
75.1
|
15
|
38
|
78
|
19 00 017 2160 06
|
5
|
|
TLYBFC-HSMS.G3
|
G3"
|
65-70
|
87.8
|
15
|
48
|
98
|
19 00 017 2180 06
|
5
|
型號
Model number
|
螺紋規格
Thread Dimension
|
接線范圍
Clamping range（mm）
|
螺紋外徑
AG（mm）
|
螺紋長度
GL
|
高度
H
|
扳手尺寸
Wrench Size（mm）
|
訂貨號
Article No.
|
包裝單位
Packet Units
|
|
TLYBFC-HSMS.PG7.A
|
PG7
|
3-6.5
|
12.5
|
5
|
19
|
14
|
9 00 017 1070 06
|
100
|
|
TLYBFC-HSMS.PG7.B
|
PG7
|
2-5
|
12.5
|
5
|
19
|
14
|
9 00 017 1071 06
|
100
|
|
TLYBFC-HSMS.PG9.A
|
PG9
|
4-8
|
15.2
|
6
|
21
|
17
|
19 00 017 1090 06
|
100
|
|
TLYBFC-HSMS.PG9.B
|
PG9
|
2-6
|
15.2
|
6
|
21
|
17
|
19 00 017 1091 06
|
100
|
|
TLYBFC-HSMS.PG11.A
|
PG11
|
5-10
|
18.6
|
6
|
22
|
20
|
19 00 017 1110 06
|
50
|
|
TLYBFC-HSMS.PG11.B
|
PG11
|
3-7
|
18.6
|
6
|
22
|
20
|
19 00 017 1111 06
|
50
|
|
TLYBFC-HSMS.PG13.5.A
|
PG13.5
|
6-12
|
20.4
|
6.5
|
24
|
22
|
19 00 017 1130 06
|
50
|
|
TLYBFC-HSMS.PG13.5.B
|
PG13.5
|
5-9
|
20.4
|
6.5
|
24
|
22
|
19 00 017 1131 06
|
50
|
|
TLYBFC-HSMS.PG16.A
|
PG16
|
10-14
|
22.5
|
6.5
|
23
|
24
|
19 00 017 1160 06
|
50
|
|
TLYBFC-HSMS.PG16.B
|
PG16
|
7-12
|
22.5
|
6.5
|
23
|
24
|
19 00 017 1161 06
|
50
|
|
TLYBFC-HSMS.PG21.A
|
PG21
|
13-18
|
28.3
|
7
|
24
|
30
|
19 00 017 1210 06
|
20
|
|
TLYBFC-HSMS.PG21.B
|
PG21
|
9-16
|
28.3
|
7
|
24
|
30
|
19 00 017 1211 06
|
20
|
|
TLYBFC-HSMS.PG29.A
|
PG29
|
18-25
|
37
|
8
|
29
|
40
|
19 00 017 1290 06
|
20
|
|
TLYBFC-HSMS.PG29.B
|
PG29
|
13-20
|
37
|
8
|
29
|
40
|
19 00 017 1291 06
|
20
|
|
TLYBFC-HSMS.PG36.A
|
PG36
|
22-32
|
47
|
8
|
35
|
50
|
19 00 017 1360 06
|
10
|
|
TLYBFC-HSMS.PG36.B
|
PG36
|
20-26
|
47
|
8
|
35
|
50
|
19 00 017 1361 06
|
10
|
|
TLYBFC-HSMS.PG42.A
|
PG42
|
32-38
|
54
|
9
|
37
|
57
|
19 00 017 1420 06
|
10
|
|
TLYBFC-HSMS.PG42.B
|
PG42
|
25-31
|
54
|
9
|
37
|
57
|
19 00 017 1421 06
|
10
|
|
TLYBFC-HSMS.PG48.A
|
PG48
|
37-44
|
59.3
|
10
|
38
|
64
|
119 00 017 1480 06
|
5
|
|
TLYBFC-HSMS.PG48.B
|
PG48
|
29-35
|
59.3
|
10
|
38
|
64
|
19 00 017 1481 06
|
5
|
型號
Model number
|
螺紋規格
Thread Dimension
|
接線范圍
Clamping range（mm）
|
螺紋外徑
AG（mm）
|
螺紋長度
GL
|
高度
H
|
扳手尺寸
Wrench Size（mm）
|
訂貨號
Article No.
|
包裝單位
Packet Units
|
|
TLYBFC-HSMS.M12.A
|
M12×1.5
|
3-6.5
|
12.0
|
6.5
|
19
|
14
|
19 00 017 0120 06
|
200
|
|
TLYBFC-HSMS.M12.B
|
M12×1.5
|
2-5
|
12.0
|
6.5
|
19
|
14
|
19 00 017 0121 06
|
2000
|
|
TLYBFC-HSMS.M16.A
|
M16×1.5
|
4-8
|
16.0
|
6
|
21
|
17/19
|
19 00 017 0160 06
|
100
|
|
TLYBFC-HSMS.M16.B
|
M16×1.5
|
2-6
|
16.0
|
6
|
21
|
17/19
|
19 00 017 0161 06
|
100
|
|
TLYBFC-HSMS.M16.C
|
M16×1.5
|
5-10
|
16.0
|
6
|
22
|
20
|
19 00 017 0162 06
|
100
|
|
TLYBFC-HSMS.M20.A
|
M20×1.5
|
6-12
|
20.0
|
6
|
23
|
22
|
19 00 017 0200 06
|
50
|
|
TLYBFC-HSMS.M20.B
|
M20×1.5
|
5-9
|
20.0
|
6
|
23
|
22
|
19 00 017 0201 06
|
50
|
|
TLYBFC-HSMS.M20.C
|
M20×1.5
|
10-14
|
20.0
|
6
|
24
|
24
|
19 00 017 0202 06
|
50
|
|
TLYBFC-HSMS.M25.A
|
M25×1.5
|
13-18
|
25.0
|
7
|
26
|
30
|
19 00 017 0250 06
|
20
|
|
TLYBFC-HSMS.M25.B
|
M25×1.5
|
9-16
|
25.0
|
7
|
26
|
30
|
19 00 017 0251 06
|
20
|
|
TLYBFC-HSMS.M32.A
|
M32×1.5
|
18-25
|
32.0
|
8
|
31
|
40
|
19 00 017 0320 06
|
20
|
|
TLYBFC-HSMS.M32.B
|
M32×1.5
|
13-20
|
32.0
|
8
|
31
|
40
|
19 00 017 0321 06
|
20
|
|
TLYBFC-HSMS.M32.C
|
M32×1.5
|
15-21
|
32.0
|
8
|
33
|
36
|
19 00 017 0322 06
|
20
|
|
TLYBFC-HSMS.M40.A
|
M40×1.5
|
22-32
|
40.0
|
8
|
37
|
50
|
19 00 017 0400 06
|
10
|
|
TLYBFC-HSMS.M40.B
|
M40×1.5
|
20-26
|
40.0
|
8
|
37
|
50
|
19 00 017 0401 06
|
10
|
|
TLYBFC-HSMS.M40.C
|
M40×1.5
|
19-27
|
40.0
|
8
|
33
|
46
|
19 00 017 0402 06
|
10
|
|
TLYBFC-HSMS.M50.A
|
M50×1.5
|
32-38
|
50.0
|
9
|
37
|
57
|
19 00 017 0500 06
|
10
|
|
TLYBFC-HSMS.M50.B
|
M50×1.5
|
25-31
|
50.0
|
9
|
37
|
57
|
19 00 017 0501 06
|
10
|
|
TLYBFC-HSMS.M63.A
|
M63×1.5
|
37-44
|
63.0
|
10
|
38
|
64/68
|
19 00 017 0630 06
|
5
|
|
TLYBFC-HSMS.M63.B
|
M63×1.5
|
29-35
|
63.0
|
10
|
38
|
64/68
|
19 00 017 0631 06
|
5
|
